No need to maintain and long life Hydraulic Gear Coupling Nylon Sleeve Gear Coupling For Water Pumps
The Hydraulic Gear Coupling Nylon Sleeve Gear Coupling is in the shape of a drum, which has high cushioning and shock absorption performance, and has great compensation ability for axial, angular and radial displacement deviation. Because engineering plastics and metal parts have good self-lubricating performance, it is a very ideal and durable coupling. The forming of the shell simplifies the processing, the process cost is low, and the assembly and maintenance are particularly simple.
Technical data of Nylon Sleeve Gear Coupling:
Motor
sixe | WilteSfMift
Dxl [mm] | n=750 [1/min] Power P | Coupling | Tk max [Nm] | n = 1000 [1/min] Power P | Coupling | Tk max [Nm] | n = 1500 [1/min] Power P | Coupling | Tk max [Nm] | n=3000(1/min] PawwP | Coupling | Tk max [Nm] |
| 1500 [1/mln] | 3000 [1/mm] | [kW] | TAN [Nm] | [kW] | TAN [Nm] | [kW] | TAN [Nm] | [kW] | TAN [Nm] |
| 56 | 9x20 | | | 14 | 20 | 0.037 | 0.43 | 14 | 20 | 0.06 | 0.4 | 14 | 20 | 0.09 | 0.3 | 14 | 20 |
| 0.045 | 0.52 | 0.09 | 0.6 | 0.12 | 0.4 |
| 63 | 11x23 | | | 14 | 20 | 0.06 | 0.7 | 14 | 20 | 0.12 | 0.9 | 14 | 20 | 0.18 | 0.6 | 14 | 20 |
| 0.09 | 1.1 | 0.18 | 1.2 | 0.25 | 0.9 |
| 71 | 14x30 | 0.09 | 1.4 | 14 | 20 | 0.18 | 2 | 14 | 20 | 0.25 | 1 | 14 | 20 | 0.37 | 1.3 | 14 | 20 |
| 0.12 | 1.8 | 0.25 | 2.8 | 0.37 | 2.5 | 0.55 | 1.9 |
| 80 | 19x40 | 0.18 | 2.5 | 19 | 32 | 0.37 | 3.7 | 19 | 32 | 0.55 | 3.7 | 19 | 32 | 0.75 | 2.5 | 19 | 32 |
| 0.25 | 3.5 | 0.55 | 5.5 | 0.75 | 5 | 1.1 | 3.7 |
| 90S | 24x50 | 0.37 | 5.3 | 24 | 40 | 0.75 | 7.9 | 24 | 40 | 1.1 | 7.5 | 24 | 40 | 1.5 | 4.9 | 24 | 40 |
| 90L | 0.55 | 7.9 | 1.1 | 11 | 1.5 | 10 | 2.2 | 7.4 |
| 100 L | 28x60 | 0.75 | 11 | 28 | 90 | 1.5 | 15 | 28 | 90 | 2.2 | 15 | 28 | 90 | 3 | 9.8 | 28 | 90 |
| 1.1 | 16 | 3 | 20 | 4 | 13 |
| 112M | 28x60 | 1.50 | 21 | 28 | 90 | 2.2 | 22 | 28 | 90 | 4 | 27 | 28 | 90 | 4 | 13 | 28 | 90 |
| 132 S | 38x80 | 2.20 | 29 | 38 | 160 | 3 | 30 | 38 | 160 | 5.5 | 36 | 38 | 160 | 5.5 | 18 | 38 | 160 |
| 7.5 | 25 |
| 132 M | 3 | 40 | 4 | 39 | 7.5 | 49 | | |
| 5.5 | 55 |
| 160M | 42x110 | 4 | 54 | 42 | 200 | 7.5 | 74 | 42 | 200 | 11 | 72 | 42 | 200 | 11 | 35 | 42 | 200 |
| 5.50 | 74 | 15 | 49 |
| 160 L | 7.50 | 100 | 11 | 108 | 15 | 98 | 18.5 | 60 |
| 180M | 48x110 | | | 48 | 280 | | | 48 | 280 | 18.5 | 121 | 48 | 280 | 22 | 72 | 48 | 280 |
| 180 L | 11 | 147 | 15 | 147 | 22 | 144 | | |
| 200L | 55x110 | 15 | 196 | 55 | 500 | 18.5 | 185 | 55 | 500 | 30 | 195 | 55 | 500 | 30 | 97 | 55 | 500 |
| 22 | 215 | 37 | 117 |
| 225 S | 60x140 | 55x110 | 18.50 | 245 | 65 | 780 | | | 65 | 780 | 37 | 245 | 65 | 780 | | | 55 | 500 |
| 225 M | 22 | 294 | 30 | 292 | 45 | 294 | 45 | 146 |
| 250 M | 65x140 | 60x140 | 30 | 390 | 65 | 780 | 37 | 361 | 65 | 780 | 55 | 357 | 65 | 780 | 55 | 176 | 65 | 780 |
| 280S | 75x140 | 65x140 | 37 | 490 | 80 | 1400 | 45 | 440 | 80 | 1400 | 75 | 487 | 80 | 1400 | 75 | 245 | 65 | 780 |
| 280 M | 45 | 585 | 55 | 536 | 90 | 584 | 90 | 294 |
| 315 S | 80x170 | 65x140 | 55 | 715 | 80 | 1400 | 75 | 730 | 80 | 1400 | 110 | 714 | 80 | 1400 | 110 | 350 | 65 | 780 |
| 315M | 75 | 970 | 100 | 2400 | 90 | 876 | 100 | 2400 | 132 | 857 | 100 | 2400 | 132 | 420 |
| 315 L | 90 | 1170 | 110 | 1070 | 160 | 1030 | 160 | 513 | 80 | 1400 |
| 110 | 1420 | 132 | 1200 | 200 | 1290 | 200 | 641 |
Hydraulic Gear Coupling Nylon Sleeve Gear Coupling is a kind of flexible coupling with good technical performance, high quality standard and low cost. Typically, nylon sleeve gear couplings consist of two symmetrical precision machined steel hubs and a nylon sleeve to ensure connection and transmission of movement. The two hubs are made of mild steel with a black oxide surface, and each hub is equipped with a universal gear outer ring. The hollow nylon sleeve is made of high molecular weight injection molding.
Hydraulic Gear Coupling Nylon Sleeve Gear Coupling have other advantages such as high thermal stability, resistance to lubricants and other chemical solutions. The double increment curve teeth of the two hubs are machined by CNC lathe to achieve excellent maintenance free performance. At the same time, they can compensate for angular and radial deviations of the dynamic type even under load. The special tooth shape structure can significantly reduce the surface pressure, improve the durability and bearing capacity of the coupling, and transmit the same torque at the same time. Transmission capacity. Nylon sleeve is suitable for use in wet environment.
